SUBMITTAL DATA LOMO PLUS SERIES: GWH18YE-D3DNA1A/O (LCLH)
The Lomo Series—a remarkable fusion of cost-effectiveness and superior performance. Designed by Gree, this series incorporates cutting-edge technology that ensures energy efficiency across all its products. Additionally, the sleek and unobtrusive design of the indoor unit in the Lomo Series seamlessly complements any home decor.
Energy Efficiency
- Experience the pinnacle of efficiency with our G10 Inverter Technology. Unlike conventional on/off systems, this advanced technology enables our system to quickly reach and maintain your desired temperature, ensuring consistent comfort. As a result, you can enjoy significant energy savings and maximize efficiency with our G10 Inverter Technology.
Home Comfort
- Experience exceptional performance even in low ambient temperatures. Our system is designed to operate efficiently and provide optimal comfort even when faced with challenging cold conditions.
- Effortlessly adjust the direction of airflow with the vertical and horizontal swing louver control feature. Customize the louver settings to achieve optimal air distribution and enhance your comfort.
- Indulge in the perfect blend of compactness and quietness with our thoughtfully designed system. Experience a space-saving solution that operates silently, providing you with a serene and comfortable environment.
Convenient Operation
- INVERTER variable speed rotary compressor with overload protection, ensuring efficient and reliable operation.
- Expand the capabilities of your unit with the optional WiFi kit, allowing for convenient remote control and management.
- Take full control of your system with the wireless remote featuring an LCD display. Enjoy the convenience of adjusting settings and monitoring your system's status with ease.
Reliable Function
- Ensure optimal performance and protection with a variable speed rotary compressor (INVERTER) equipped with overload protection.
- Enjoy the benefits of intelligent defrost technology, which ensures efficient and effective defrosting while minimizing energy consumption. Experience uninterrupted performance and optimal heating even during frosty conditions.
- Benefit from the robust construction of a heavy gauge steel cabinet, ensuring durability and longevity for your system.
- Washable filters: Our system features washable filters that can be easily removed and cleaned, allowing for effortless maintenance and improved air quality.
- Enjoy long-lasting durability and enhanced corrosion resistance with fins featuring a protective anti-corrosion coating.
Warranty Coverage
Airtek/Gress proudly backs all their models with a robust manufacturer's warranty. This comprehensive warranty spans an impressive 10 years, safeguarding your investment. Rest assured, any warranty claims you may have will be efficiently handled by Airtek/Gress's, guaranteeing top-tier customer support and satisfaction. The 10-year warranty encompasses the compressor, while other parts enjoy coverage for 5 years. With this warranty, you can trust in the long-term protection of your purchase, ensuring you receive the utmost quality.
| GENERAL FEATURES | |
| Compact and Quote Design | |
| Wireless Remote with LCD Display | |
| Wired Controller (Optional) | |
| Wifi Control Capability | |
| Power supply from Outdoor unit | |
| Auto Swing (Vertical & Horizontal Auto Swing) | |
| Low ambient temperature | |
| Intelligent Defrost | |
| Refrigerant 410a | |
| Electronic expansion valve | |
| 10 years unlimited parts warranty | |
| Cooling | |
| Rated Capacity | 18,000 Btu/h |
| Capacity Range | 4,094 - 21,836 Btu/h |
| Power Input (Max) | 2,500 W |
| SEER | 24.50 |
| HSPF | 12.00 |
| Heating | |
| Heating Capacity | 18,000 Btu/h |
| Capacity Range | 4,094 - 24,566 Btu/h |
| Power Input (Max) | 2,500 W |
| COP | 3.52 W/W |
| EER | 3.97 W/W |
| Set Temperature Range | 16 ~ 30 °C |
| Indoor Unit Data | |
| Air Flow Volume | 1250/1150/950/780/600 m3/h |
| Sound Pressure Level | 51/48/42/36/34 dB(A) |
| Fan motor output power | 60 W |
| Fan motor RLA | 0.24 A |
| Outdoor Unit Data | |
| Power supply | 208-230V/60Hz/1Ph |
| Compressor RLA | 15.5 A |
| Sound Pressure Level | 59 dB(A) |
| MOCP | 30 A |
| MCA | 22 A |
| Ambient temp range cooling/heating | -18 ~ 54 -30 ~ 24 °C |
| Physical & Piping | |
| Indoor Unit | |
| Unit Dimensions (LxHXD) | 1078√ó325x246 MM |
| Weight | 44 lb |
| Outdoor Unit | |
| Unit Dimensions (LxHXD) MM | 980√ó790√ó427 |
| Weight | 141 lb |
| Max. Height Distance | 65 ft |
| Minimum/Maximum length | 10 ft/98.40 ft |
| Pre Charged refrigerant | 70 oz - good for 24 ft - R410a |
| Add. Refrigerant Charge | 0.5 Oz/ft |
| Liquid/Gas Line connection | 1/4 in & 5/8 in |
Documentations and Certifications
Gree Error Codes
- E1 - Compressor high pressure protection
- E3 - Compressor low pressure protection
- E4 - Compressor air discharge high-temperature protection
- F2 - Condenser temperature sensor error
- F3 - Outdoor ambient temperature sensor error
- F4 - Discharge temperature sensor error
- F6 - ODU tube temperature sensor error
- EE - ODU memory chip error
- H4 - Overload
- H5 - IPM protection
- H6 - DC fan error
- H7 - Driver out-of-step protection
- HC - Pfc protection
- Lc - Startup failure
- P0 - Driver reset protection
- P5 - Over-current protection
- P6 - Master control and driver communication error
- P7 - Driver module sensor error
- P8 - Driver module high temperature protection
- PA - AC current protection
- Pc - Driver current error
- PL - Bus low-voltage protection
- PH - Bus high-voltage protection
- PU - Charge loop error
- ee - Drive memory chip error
- e1 - High pressure sensor error
- C4 - ODU jumper cap error
